Pogo Pin Connectors_6Pin_2.5mm Pitch_SMD Vertical Series
| Technology | N/A | Working Height | 4.0 mm |
|---|---|---|---|
| Working Range(Reference) | 3.7mm~4.3mm | Plug/Rece(Male/Female) | Male |
| Row | Single | Boss | W/O |
| Number of Pins | 6 | Pitch | 2.5 mm |
| Spring Force | 1.08 N | Rated Current | 2A |
| Rated Voltage | AC/DC 12V | Contact Resistance | 50mΩ |
| Operation Temp Range | -40℃〜＋85℃ | Cycle Durability | 20,000 times |
| Soldering Method | SMD_Vertical | Compatible Product | J-4000H-6-25-0000 |
| CAP | W | Packaging | Tape&Reel |
| Packaging Quantity | 1,500pcs |
